描述
| 额定一次电流(A) | 额定二次电流(A) | 准确级组合 | 额定输出(VA) | 额定短时热电流(Ith)(kA) | 额定动稳定电流(Idyn)(kA) |
| 20 | 5 | 0.2/10P10 0.2/10P20 0.5/10P10 0.5/10P20 10P10/10P10 10P20/10P20 0.2/0.5/10P10 0.2/0.5/10P20 0.2/10P10/10P10 0.2/10P10/10P20 0.5/10P10/10P10 0.5/10P10/10P20 |
20/50 20/25 50/50 50/25 50/50 25/25 15/50/50 15/50/25 15/25/50 15/25/25 50/25/50 50/25/25 |
1.3 | 3.25 |
| 30 | 2 | 5 | |||
| 40 | 3 | 7.5 | |||
| 50 | 4.5 | 11.5 | |||
| 75 | 6 | 15 | |||
| 100 | 9 | 22.5 | |||
| 150 | 12 | 30 | |||
| 200 | 18 | 45 | |||
| 300 | 24 | 60 | |||
| 400 | 36 | 90 | |||
| 600 | 48 | 120 | |||
| 800 | |||||
| 1000 | |||||
| 1200 | |||||
| 1500 |
